JBL JBLSTUDIO530BK-Z Studio 530 Bookshelf Speakers - Certified Refurbished
Description
JBL JBLSTUDIO530BK-Z Studio 530 Bookshelf Speakers - Certified Refurbished
Description
The most advanced JBL residential loudspeaker systems, including Everest DD66000, K2 and Project Array, share one key design characteristic with the massive JBL Professional systems you hear in premier movie houses and concert venues. All employ constant-directivity compression drivers in a horn to deliver the high-impact dynamics and dimensional realism that large audiences and critical listeners demand. Now JBL Studio 5 Series speakers, designed by renowned JBL chief engineer Greg Timbers, continue this performance-proven tradition. The JBL Studio 530 bookshelf loudspeaker combines a 1-Inch (25mm) HF compression driver and Bi-Radial horn with 5-1/4-Inch (130mm) cast-frame Symmetrical Field Geometry (SFG) woofer to deliver extraordinarily lifelike performance. Ideal for both music and movie systems, the Studio 530 system is powerful, accurate and styled to make a dramatic design statement in any listening environment.
Features
- 5-1/4" (130mm) Low-Frequency Transducer
- 1" (25mm) High-Frequency Compression Driver
- Glass-filled ABS Bi-Radial High-Frequency Horn
- 3/4" (19mm) MDF Enclosure
- Low loss, 2-way crossover network
- Rear-facing bass port increases output and extends bass response
- Dual gold-plated binding posts with bi-wire capability increases connection options
- Exclusive Design
5-1/4" (130mm) Low-Frequency Transducer
The 5-1/4" (130mm) Low-Frequency Transducer on the JBL Studio 530BK is equipped with stiff, lightweight ribbed PolyPlas cones with rubber surround and 1-1/2"-diameter woofer voice coils. The heavy-duty magnet assemblies with Symmetrical Field Geometry (SFG) technology and delivers clean, powerful bass response at all listening levels. All of this technology is beautifully stored in a rigid, non-resonant cast aluminum frame, resulting in a crisp, high-impact bass performance and more emotional impact at all listening levels.
1" (25mm) High-Frequency Compression Driver
The one-piece Teonex® diaphragm/surround with 1" voice coil produces a significantly lower distortion and greater dynamic range than conventional midrange and HF drivers. This feature vastly improves realism and clarity, espeically at lower output levels.
Glass-filled ABS Bi-Radial High-Frequency Horn
The glass- filled ABS Bi-Radial High-Frequency Horn is controlled directivity at ear level of seated listeners minimizes unwanted HF interaction with walls and furniture with cleaner, more realistic HF sound over a wider listening area.
3/4" (19mm) MDF Enclosure
The rigid, heavily-braced design with non-parallel surfaces reduces unwanted resonances. Such enclosure provides a clearer, more detailed sound.
Low loss, 2-way crossover network
The 2-way crossover network smoothes transition between woofers and HF compression driver/horn. The crossover network produces reduced distortion and coloration for improved sonic clarity.
Exclusive Design
Clean and Dynamic, one-of-a-kind look makes a dramatic design statement in any room. JBL Studio 530 is available in front- to-back black finish.
Specifications
| Low-frequency transducer | 5-1/4" (130mm) PolyPlas™ cone with SFG magnet structure, cast frame and rubber surround, magnetically shielded |
| High-frequency transducer | 1" (25mm) compression driver with neodymium magnet and one-piece Teonex® diaphragm on a glass-filled ABS Bi-Radial® horn, magnetically shielded |
| Recommended amplifier power | 125 watts |
| Frequency response | 45Hz – 40kHz (–6dB) |
| Nominal impedance | 6 ohms |
| Sensitivity (2.83V/1m) | 86dB |
| Crossover frequencies | 1.5kHz |
| Enclosure type | Ported |
| Connector type | Dual gold-plated binding posts (bi-wire-capable) |
| Available finishes | Black |
| Dimensions (H x W x D) | 18-3/8" x 8-7/16" x 8-3/4" (467mm x 214mm x 222mm) |
| Weight | 17 lb (7.7kg) |
